TLC272BCPS
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLC272 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 0.0006muA 2mV 1700kHz 2.2MHz
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.32352
≥100 USD $1.06392
≥500 USD $0.99902
Inventory: 542
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series LinCMOS?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Base Part Number TLC272
Pin Count 8
Number of Elements 2
Operating Supply Current 1.9mA
Nominal Supply Current 3.2mA
Slew Rate 5.3V/μs
Amplifier Type General Purpose
Common Mode Rejection Ratio 65 dB
Current - Input Bias 0.7pA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Output Current per Channel 30mA
Input Offset Voltage (Vos) 2mV
Gain Bandwidth Product 2.2MHz
Unity Gain BW-Nom 1700 kHz
Voltage Gain 87.23dB
Average Bias Current-Max (IIB) 0.0006μA
Voltage - Input Offset 290μV
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
