TLC272AIDG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Rail/Tube op amp buffer circuit 4.9mm 0.00006muA 5mV 1700kHz
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.653657
≥1 USD $0.653657
≥10 USD $0.616663
≥100 USD $0.581755
≥500 USD $0.548821
≥1000 USD $0.517758
Inventory: 1213
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Max I/O Voltage 5mV
Nominal Gain Bandwidth Product 1.7MHz
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00006μA
Micropower NO
Low-Bias YES
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.00006μA
Voltage Gain 87.23dB
Unity Gain BW-Nom 1700 kHz
Gain Bandwidth Product 1.7MHz
Bandwidth 1.7MHz
Input Offset Voltage (Vos) 5mV
Output Current per Channel 30mA
Current - Input Bias 60pA
Common Mode Rejection Ratio 65 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 3.6 V/μs
Power Dissipation 725mW
Nominal Supply Current 4mA
Operating Supply Current 1.4mA
Min Supply Voltage 4V
Max Supply Voltage 16V
Temperature Grade INDUSTRIAL
Number of Elements 2
Pin Count 8
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Rail/Tube
Physical
Number of Pins 8
Surface Mount YES
Package / Case SOIC
