TLC271MD
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Not Qualified GULL WING OPERATIONAL AMPLIFIER CMOS op amp buffer circuit 80dB 2.9V/us 125C 1700kHz
PDF
/
Inventory: 7516
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Common-mode Reject Ratio-Min 65 dB
Voltage Gain-Min 10000
Input Offset Voltage-Max 12000μV
Programmable Power YES
Low-Bias YES
Supply Voltage Limit-Max 18V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.00006μA
Unity Gain BW-Nom 1700 kHz
Common Mode Rejection Ratio 80 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 2.9 V/us
Temperature Grade MILITARY
Power Supplies 5/10V
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
HTS Code 8542.33.00.01
ECCN Code EAR99
Number of Terminations 8
Physical
Surface Mount YES
