TLC1078IDG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLC1078 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 4.9mm 0.00006muA 450muV 85kHz
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.841868
≥1 USD $2.841868
≥10 USD $2.681008
≥100 USD $2.529249
≥500 USD $2.386084
≥1000 USD $2.251022
Inventory: 1275
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Input Offset Current-Max (IIO) 0.00006μA
Max I/O Voltage 450μV
Nominal Gain Bandwidth Product 85 kHz
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00006μA
Micropower YES
Low-Bias YES
Voltage - Input Offset 180μV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.00006μA
Voltage Gain 114.4dB
Unity Gain BW-Nom 85 kHz
Bandwidth 110 kHz
Input Offset Voltage (Vos) 450μV
Output Current per Channel 30mA
Voltage - Supply, Single/Dual (±) 3V~16V
Current - Input Bias 0.7pA
Common Mode Rejection Ratio 70 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.047V/μs
Output Current 20mA
Power Dissipation 725mW
Nominal Supply Current 46μA
Operating Supply Current 29μA
Power Supplies 5/10V
Number of Elements 2
Pin Count 8
Base Part Number TLC1078
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series LinCMOS?
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
