TLC084CDRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Tape and Reel op amp buffer circuit 8.65mm 0.0001muA 1.9mV 10000kHz
PDF
/
Inventory: 1097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Max I/O Voltage 1.9mV
Nominal Gain Bandwidth Product 10MHz
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00005μA
Min Dual Supply Voltage 2.25V
Micropower NO
Low-Bias YES
Max Dual Supply Voltage 8V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0001μA
Voltage Gain 120dB
Unity Gain BW-Nom 10000 kHz
Gain Bandwidth Product 10MHz
Bandwidth 10MHz
Input Offset Voltage (Vos) 1.9mV
Output Current per Channel 57mA
Current - Input Bias 50pA
Common Mode Rejection Ratio 80 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 16 V/μs
Current - Output 57mA
Power Dissipation 1.022W
Nominal Supply Current 11.6mA
Operating Supply Current 1.9mA
Min Supply Voltage 4.5V
Max Supply Voltage 16V
Temperature Grade COMMERCIAL
Number of Elements 4
Operating Supply Voltage 8V
Pin Count 14
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIMOS
Subcategory Operational Amplifier
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Tape and Reel
Physical
Number of Pins 14
Surface Mount YES
Package / Case SOIC
