TLC083CDG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING Surface Mount General Purpose Amplifier 80dB 19V/mus 0C~70C 10MHz
PDF
/
Buying Options
Total Price: USD $7.09
Unit Price: USD $7.090847
≥1 USD $7.090847
≥10 USD $6.68947
≥100 USD $6.310822
≥500 USD $5.953603
≥1000 USD $5.616605
Inventory: 955
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Power NO
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00005μA
Micropower NO
Low-Bias YES
Supply Voltage Limit-Max 17V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0001μA
Voltage Gain 120dB
Unity Gain BW-Nom 10000 kHz
Bandwidth 10MHz
Input Offset Voltage (Vos) 390μV
Output Current per Channel 57mA
Voltage - Supply, Single/Dual (±) 4.5V~16V ±2.25V~8V
Current - Input Bias 2pA
Common Mode Rejection Ratio 80 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 19V/μs
Output Current 57mA
Nominal Supply Current 5.8mA
Operating Supply Current 1.9mA
Number of Circuits 2
Operating Supply Voltage 8V
Qualification Status Not Qualified
Pin Count 14
Base Part Number TLC083
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIMOS
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
