TL972IDRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free GULL WING Rail-to-Rail Surface Mount General Purpose Amplifier 60dB 5V/mus -40C~125C 12MHz
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.52345
≥1 USD $0.52345
≥10 USD $0.43035
≥100 USD $0.4161
≥500 USD $0.4028
≥1000 USD $0.3895
Inventory: 19927
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Input Offset Current-Max (IIO) 0.15μA
Power NO
Max I/O Voltage 4mV
Nominal Gain Bandwidth Product 12MHz
Programmable Power NO
Bias Current-Max (IIB) @25C 0.75μA
Micropower NO
Low-Bias NO
Supply Voltage Limit-Max 15V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.75μA
Voltage Gain 80dB
Unity Gain BW-Nom 12000 kHz
Neg Supply Voltage-Nom (Vsup) -2.5V
Bandwidth 12MHz
Input Offset Voltage (Vos) 1mV
Output Current per Channel 80mA
Voltage - Supply, Single/Dual (±) 2.7V~12V ±1.35V~6V
Current - Input Bias 200nA
Common Mode Rejection Ratio 60 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 5V/μs
Nominal Supply Current 2.8mA
Operating Supply Current 2mA
Number of Circuits 2
Operating Supply Voltage 6V
Output Type Rail-to-Rail
Pin Count 14
Base Part Number TL972
Supply Voltage 2.5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 12 Weeks
