TL431ACPS
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free Not Qualified GULL WING BIPOLAR op amp buffer circuit 70C 2.495V 6.2mm
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
Inventory: 6941
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Length 6.2mm
Height Seated (Max) 2mm
Technical
Temp Coef of Voltage-Max 143.143 ppm/°C
Output Voltage-Min 2.47V
Output Voltage-Max 2.52V
Voltage Tolerance-Max 1%
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Supply Voltage-Min (Vsup) 2.495V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 36V
Output Voltage 2.495V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Additional Feature OUTPUT VOLTAGE ADJUSTABLE FROM 2.495V TO 36V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Physical
Number of Pins 8
Surface Mount YES
