TL072BCD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TL072 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 4.9mm 0.007muA 9V 3000kHz
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.92312
≥100 USD $0.876014
≥500 USD $0.71955
≥1000 USD $0.672646
≥3000 USD $0.594431
Inventory: 4118
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 15V
Base Part Number TL072
Pin Count 8
Operating Supply Voltage 18V
Power Supplies +-15V
Number of Channels 2
Operating Supply Current 1.4mA
Nominal Supply Current 5mA
Slew Rate 13V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type J-FET
Common Mode Rejection Ratio 75 dB
Current - Input Bias 65pA
Voltage - Supply, Single/Dual (±) ±5V~15V
Input Offset Voltage (Vos) 3mV
Bandwidth 3MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 3000 kHz
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.007μA
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 2mV
Low-Bias YES
Micropower NO
Programmable Power NO
Dual Supply Voltage 9V
Nominal Gain Bandwidth Product 3MHz
Max I/O Voltage 3mV
Power NO
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
