TL064CDE4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TL064 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 8.65mm 0.01muA 15mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.589492
≥1 USD $0.589492
≥200 USD $0.228445
≥500 USD $0.220567
≥1000 USD $0.216629
Inventory: 1157
Minimum: 1
-
+
Technical Details
Technical
Number of Elements 4
Power Supplies +-15V
Operating Supply Current 200μA
Nominal Supply Current 1mA
Slew Rate 3.5V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type J-FET
Common Mode Rejection Ratio 70 dB
Current - Input Bias 30pA
Voltage - Supply, Single/Dual (±) 7V~36V ±3.5V~18V
Input Offset Voltage (Vos) 15mV
Bandwidth 1MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 1000 kHz
Voltage Gain 75.56dB
Average Bias Current-Max (IIB) 0.01μA
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 3mV
Low-Bias YES
Micropower YES
Programmable Power NO
Nominal Gain Bandwidth Product 1MHz
Max I/O Voltage 15mV
Input Offset Current-Max (IIO) 0.0002μA
Operating Supply Voltage 18V
Pin Count 14
Base Part Number TL064
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
