TL062ACDRE4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free GULL WING Surface Mount J-FET J-FET Amplifier 80dB 3.5V/mus 0C~70C 1MHz
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.671009
≥1 USD $0.671009
≥10 USD $0.633029
≥100 USD $0.597197
≥500 USD $0.563391
≥1000 USD $0.531495
Inventory: 1196
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 15V
Base Part Number TL062
Pin Count 8
Operating Supply Voltage 18V
Number of Elements 2
Power Supplies +-15V
Operating Supply Current 200μA
Nominal Supply Current 500μA
Slew Rate 3.5V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type J-FET
Common Mode Rejection Ratio 80 dB
Current - Input Bias 30pA
Voltage - Supply, Single/Dual (±) 7V~36V ±3.5V~18V
Input Offset Voltage (Vos) 6mV
Bandwidth 1MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 1000 kHz
Voltage Gain 75.56dB
Average Bias Current-Max (IIB) 0.007μA
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 3mV
Low-Bias YES
Micropower YES
Programmable Power NO
Nominal Gain Bandwidth Product 1MHz
Max I/O Voltage 6mV
Input Offset Current-Max (IIO) 0.0001μA
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
