THS4500MDGNEP
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 THS4500 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 3mm 6.6muA 6mV 300000kHz
PDF
/
Buying Options
Total Price: USD $16.33
Unit Price: USD $16.331163
≥1 USD $16.331163
≥200 USD $6.320301
≥500 USD $6.098421
≥1000 USD $5.988137
Inventory: 1095
Minimum: 1
-
+
Technical Details
Technical
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -55°C~125°C
Input Offset Current-Max (IIO) 2μA
Programmable Power NO
Bias Current-Max (IIB) @25C 6.6μA
-3db Bandwidth 30MHz
Micropower NO
Low-Bias NO
Current - Output / Channel 120mA
Settling Time 8.3 ns
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 70dB
Average Bias Current-Max (IIB) 6.6μA
Unity Gain BW-Nom 300000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 300MHz
Bandwidth 370MHz
Input Offset Voltage (Vos) 6mV
Output Current per Channel 150mA
Voltage - Supply, Single/Dual (±) 4.5V~15V
Max Input Voltage 15V
Current - Input Bias 6.6μA
Common Mode Rejection Ratio 70 dB
Amplifier Type Differential
Architecture VOLTAGE-FEEDBACK
Slew Rate 2800V/μs
Min Input Voltage 5V
Output Current 150mA
Nominal Supply Current 40mA
Number of Circuits 1
Output Type Differential, Rail-to-Rail
Pin Count 8
Base Part Number THS4500
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Operational Amplifier
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 16 Weeks
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Thickness 1.02mm
Width 3mm
Length 3mm
Height 1.1mm
