THS4082CDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 THS4082 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 4.9mm 1.2muA 5V 79dB
PDF
/
Buying Options
Total Price: USD $2.94
Unit Price: USD $2.945
≥1 USD $2.945
≥10 USD $2.4168
≥100 USD $2.3408
≥500 USD $2.26575
≥1000 USD $2.18975
Inventory: 7924
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Max I/O Voltage 4.5mV
Consumer IC Type VIDEO AMPLIFIER
Settling Time 43 ns
Voltage - Input Offset 1mV
Power Supply Rejection Ratio (PSRR) 79dB
Voltage Gain 84.08dB
Gain Bandwidth Product 100MHz
Bandwidth 175MHz
Input Offset Voltage (Vos) 7mV
Output Current per Channel 85mA
Voltage - Supply, Single/Dual (±) 10V~30V ±5V~15V
Current - Input Bias 1.2μA
Common Mode Rejection Ratio 84 dB
Amplifier Type Voltage Feedback
Slew Rate 230V/μs
Power Dissipation 740mW
Nominal Supply Current 8.4mA
Operating Supply Current 3.4mA
Number of Channels 1
Supply Voltage-Min (Vsup) 5V
Supply Voltage-Max (Vsup) 15V
Number of Elements 2
Pin Count 8
Base Part Number THS4082
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 740mW
Additional Feature IT CAN ALSO OPERATE WITH 10V TO 30V SINGLE SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 75.891673mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
