PGA207UA/1K
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 PGA207 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 10.3mm 2pA 15V 5MHz
PDF
/
Buying Options
Total Price: USD $26.55
Unit Price: USD $26.552829
≥1 USD $26.552829
≥10 USD $25.453983
≥100 USD $32.43775
≥500 USD $31.3918
≥1000 USD $30.34585
Inventory: 20
Minimum: 1
-
+
Technical Details
Technical
Voltage Gain-Min 1
Input Voltage Noise Density 18nV/sqrt Hz
Voltage Gain-Nom 2
Non-linearity-Max 0.005%
Voltage Gain-Max 10
Dual Supply Voltage 15V
-3db Bandwidth 5MHz
Settling Time 3.5 μs
Voltage - Input Offset 1mV
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 5MHz
Input Offset Voltage (Vos) 2.5mV
Output Current per Channel 17mA
Voltage - Supply, Single/Dual (±) 9V~36V ±4.5V~18V
Current - Input Bias 2pA
Common Mode Rejection Ratio 75 dB
Amplifier Type Instrumentation
Slew Rate 25V/μs
Quiescent Current 12.4mA
Operating Supply Current 13.5mA
Number of Circuits 1
Number of Elements 3
Pin Count 16
Base Part Number PGA207
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 420.395078mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
