OPA860IDG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) SOIC op amp amplifier circuit 4.9mm 5muA 3mV 0dB
PDF
/
Buying Options
Total Price: USD $6.34
Unit Price: USD $6.344026
≥1 USD $6.344026
≥10 USD $5.984936
≥100 USD $5.646158
≥500 USD $5.326565
≥1000 USD $5.02506
Inventory: 1230
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Weight 75.891673mg
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 2
Number of Terminations 8
ECCN Code EAR99
Resistance 1MOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology BIPOLAR
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
Qualification Status Not Qualified
Number of Elements 1
Temperature Grade INDUSTRIAL
Max Supply Voltage 13V
Min Supply Voltage 5V
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 11.2mA
Current - Output 10mA
Slew Rate 3500 V/μs
Current - Input Bias 5μA
Output Current per Channel 15mA
Supply Type Dual
Input Offset Voltage (Vos) 3mV
Gain Bandwidth Product 470MHz
Neg Supply Voltage-Nom (Vsup) -5V
Voltage Gain 0dB
Max Dual Supply Voltage 6.5V
Min Dual Supply Voltage 2.5V
Max I/O Voltage 12mV
Input Voltage Noise Density 3.4nV/sqrt Hz
Dimensions
Length 4.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
