OPA698MJD
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead OPERATIONAL AMPLIFIER MILITARY DUAL op amp amplifier circuit 50dB 820V/mus 125C 230MHz
PDF
/
Buying Options
Total Price: USD $60.54
Unit Price: USD $60.544
≥1 USD $60.544
Inventory: 91
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 3.5mm
Width 7.37mm
Length 10.29mm
Height 4.45mm
Technical
Input Offset Current-Max (IIO) 2μA
Wideband YES
Dual Supply Voltage 5V
Programmable Power NO
Min Dual Supply Voltage 2.5V
Micropower NO
Low-Bias NO
Max Dual Supply Voltage 6V
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 58dB
Voltage Gain 57dB
Unity Gain BW-Nom 200000 kHz
Neg Supply Voltage-Nom (Vsup) -5V
Gain Bandwidth Product 230MHz
Input Offset Voltage (Vos) 8mV
Current - Input Bias 10μA
Common Mode Rejection Ratio 50 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 820 V/μs
Min Supply Voltage 5V
Max Supply Voltage 12V
Temperature Grade MILITARY
Number of Elements 1
Pin Count 8
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Subcategory Operational Amplifier
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 8
Packaging Rail/Tube
Physical
Number of Pins 8
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
