OPA687N/3K
RoHS
/
Package SOT-23-6
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING OPERATIONAL AMPLIFIER op amp amplifier circuit 100dB 900V/mus 85C 3.8GHz
PDF
/
Buying Options
Total Price: USD $2.45
Unit Price: USD $2.447302
≥1 USD $2.447302
≥10 USD $2.308781
≥100 USD $2.178092
≥500 USD $2.054801
≥1000 USD $1.938492
Inventory: 1595
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOT-23-6
Technical
Packaging Tape & Reel (TR)
Pbfree Code no
Number of Terminations 6
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Operational Amplifiers
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.95mm
Pin Count 6
JESD-30 Code R-PDSO-G6
Qualification Status Not Qualified
Power Supplies +-5V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Operating Supply Current 18.5mA
Supply Current-Max 20.5mA
Slew Rate 900 V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 100 dB
Current - Input Bias 20μA
Output Current per Channel 80mA
Input Offset Voltage (Vos) 100μV
Gain Bandwidth Product 3.8 GHz
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 3800000 kHz
Average Bias Current-Max (IIB) 40μA
Low-Offset NO
Supply Voltage Limit-Max 6.5V
Low-Bias NO
Micropower NO
Bias Current-Max (IIB) @25C 33μA
Programmable Power NO
Neg Supply Voltage-Max (Vsup) -6.5V
Wideband YES
Power NO
Dimensions
Length 2.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
