OPA627BP
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 OPA627 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 9.81mm 0.000005muA 15V 16000kHz
PDF
/
Buying Options
Total Price: USD $77.1
Unit Price: USD $77.102
≥1 USD $77.102
≥10 USD $74.6928
≥100 USD $72.28265
≥500 USD $69.87345
≥1000 USD $62.6449
Inventory: 141
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Weight 440.409842mg
Technical
Operating Temperature -25°C~85°C
Packaging Tube
Series Difet?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Max Power Dissipation 1W
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 2.54mm
Base Part Number OPA627
Pin Count 8
Operating Supply Voltage 36V
Number of Channels 1
Operating Supply Current 7mA
Nominal Supply Current 7mA
Power Dissipation 1W
Slew Rate 55V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 106 dB
Current - Input Bias 1pA
Voltage - Supply, Single/Dual (±) 9V~36V ±4.5V~18V
Output Current per Channel 45mA
Input Offset Voltage (Vos) 250μV
Bandwidth 16MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 16000 kHz
Voltage Gain 120dB
Power Supply Rejection Ratio (PSRR) 106dB
Low-Offset YES
Frequency Compensation YES
Voltage - Input Offset 40μV
Low-Bias YES
Micropower NO
Bias Current-Max (IIB) @25C 0.000005μA
Programmable Power NO
Dual Supply Voltage 15V
Nominal Gain Bandwidth Product 16MHz
Input Offset Current-Max (IIO) 0.000005μA
Input Voltage Noise Density 15nV/sqrt Hz
Dimensions
Height 5.08mm
Length 9.81mm
Width 6.35mm
Thickness 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
