OPA512SM
RoHS
RoHS compliant
RoHS compliantPackage TO-3-8
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant O-MBFM-P8 OPA512 Tube op amp amplifier circuit 0.02muA 3mV 4000kHz 4MHz
PDF
/
Buying Options
Total Price: USD $242.72
Unit Price: USD $242.717631
≥1 USD $242.717631
≥10 USD $228.978892
≥100 USD $216.017822
≥500 USD $203.790396
≥1000 USD $192.255097
Inventory: 1137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
Bias Current-Max (IIB) @25C 0.02μA
Voltage - Input Offset 1mV
Supply Voltage Limit-Max 50V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.02μA
Voltage Gain 110dB
Unity Gain BW-Nom 4000 kHz
Neg Supply Voltage-Nom (Vsup) -40V
Gain Bandwidth Product 4MHz
Input Offset Voltage (Vos) 3mV
Output Current per Channel 15A
Voltage - Supply, Single/Dual (±) 20V~100V ±10V~50V
Current - Input Bias 10nA
Common Mode Rejection Ratio 74 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 4V/μs
Output Current 15A
Power Dissipation 125W
Nominal Supply Current 35mA
Operating Supply Current 25mA
Power Supplies +-40V
Number of Elements 1
Operating Supply Voltage 45V
Qualification Status Not Qualified
JESD-30 Code O-MBFM-P8
Pin Count 2
Base Part Number OPA512
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 40V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position BOTTOM
Technology HYBRID
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Package / Case TO-3-8
Mounting Type Through Hole
Mount Through Hole
