OPA341NA/3K
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 OPA341 Cut Tape (CT) op amp buffer circuit 2.9mm 0.6pA 6mV 5500kHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
≥3000 USD $0.3686
Inventory: 5334
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Max I/O Voltage 6mV
Nominal Gain Bandwidth Product 5.5MHz
Programmable Power NO
Micropower NO
Low-Bias YES
Current - Output / Channel 50mA
Voltage - Input Offset 2mV
Supply Voltage Limit-Max 6V
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 87.96dB
Voltage Gain 120dB
Unity Gain BW-Nom 5500 kHz
Bandwidth 5.5MHz
Input Offset Voltage (Vos) 6mV
Voltage - Supply, Single/Dual (±) 2.5V~5.5V
Current - Input Bias 0.6pA
Common Mode Rejection Ratio 76 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 6V/μs
Current - Supply 750μA
Output Current 50mA
Nominal Supply Current 1mA
Power Supplies 2.7/5.5V
Number of Elements 1
Output Type Rail-to-Rail
Pin Count 6
Base Part Number OPA341
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MicroAmplifier?
Packaging Cut Tape (CT)
Operating Temperature -55°C~125°C
Physical
Number of Pins 6
Surface Mount YES
Package / Case SOT-23-6
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
