OPA337PAG4
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 OPA337 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 9.81mm 0.2pA 3mV 3000kHz
PDF
/
Buying Options
Total Price: USD $4.5
Unit Price: USD $4.495939
≥1 USD $4.495939
≥10 USD $4.241452
≥100 USD $4.001371
≥500 USD $3.774879
≥1000 USD $3.561205
Inventory: 1461
Minimum: 1
-
+
Technical Details
Technical
Slew Rate 1.2V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 74 dB
Current - Input Bias 0.2pA
Voltage - Supply, Single/Dual (±) 2.7V~5.5V ±1.35V~2.75V
Output Current per Channel 9mA
Input Offset Voltage (Vos) 3mV
Bandwidth 3MHz
Unity Gain BW-Nom 3000 kHz
Voltage Gain 120dB
Power Supply Rejection Ratio (PSRR) 92.04dB
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 7.5V
Voltage - Input Offset 500μV
Low-Bias YES
Micropower NO
Programmable Power NO
Nominal Gain Bandwidth Product 3MHz
Max I/O Voltage 3mV
Nominal Supply Current 1mA
Operating Supply Current 525μA
Power Supplies 3/5V
Number of Elements 1
Output Type Rail-to-Rail
Pin Count 8
Base Part Number OPA337
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series MicroAmplifier?
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 4.57mm
Length 9.81mm
Width 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
