OPA330AIDCKR
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 OPA330 Tape & Reel (TR) op amp amplifier circuit 2mm 200pA 50muV 350kHz
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.7776
≥1 USD $1.7776
≥10 USD $1.5972
≥100 USD $1.50656
≥500 USD $1.283568
≥1000 USD $1.205213
≥3000 USD $1.054557
Inventory: 1116
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 1.25mm
Length 2mm
Height 1.1mm
Technical
Power NO
Programmable Power NO
Micropower YES
Low-Bias YES
Voltage - Input Offset 8μV
Supply Voltage Limit-Max 7V
Frequency Compensation YES
Low-Offset YES
Voltage Gain 115dB
Unity Gain BW-Nom 350 kHz
Bandwidth 350 kHz
Input Offset Voltage (Vos) 50μV
Output Current per Channel 5mA
Voltage - Supply, Single/Dual (±) 1.8V~5.5V ±0.9V~2.75V
Current - Input Bias 200pA
Common Mode Rejection Ratio 100 dB
Amplifier Type Zero-Drift
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.16V/μs
Output Current 5mA
Nominal Supply Current 21μA
Operating Supply Current 21μA
Number of Elements 1
Output Type Rail-to-Rail
Pin Count 5
Base Part Number OPA330
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
