RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description Contains Lead Not Qualified GULL WING BUFFER op amp buffer circuit 2100V/mus -40C 330MHz 7500muV
PDF
/
Inventory: 6523
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm

Technical

Input Offset Voltage-Max 7500μV
Neg Supply Voltage-Max (Vsup) -6.5V
Bias Current-Max (IIB) @25C 55μA
-3db Bandwidth 330MHz
Supply Voltage Limit-Max 6.5V
Neg Supply Voltage-Nom (Vsup) -5V
Amplifier Type BUFFER
Slew Rate 2100 V/μs
Number of Circuits 2
Temperature Grade INDUSTRIAL
Power Supplies 5/+-5V
Operating Temperature (Min) -40°C
Qualification Status Not Qualified
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Buffer Amplifier
ECCN Code EAR99
Number of Terminations 8
Pbfree Code no
Packaging Bulk

Physical

Number of Pins 8
Surface Mount YES
Package / Case SOIC
