OPA131PA
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified THROUGH-HOLE OPERATIONAL AMPLIFIER op amp amplifier circuit 80dB 10V/us 85C 4MHz
PDF
/
Buying Options
Total Price: USD $210.55
Unit Price: USD $210.553276
≥1 USD $210.553276
≥10 USD $203.629861
≥25 USD $202.214366
≥50 USD $200.808696
≥100 USD $196.678455
≥500 USD $182.616948
Inventory: 3866
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 5.08mm
Technical
Voltage Gain-Min 50000
Input Offset Current-Max (IIO) 0.00005μA
Bias Current-Max (IIB) @25C 0.00005μA
Low-Bias YES
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.00005μA
Unity Gain BW-Nom 4000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 4MHz
Common Mode Rejection Ratio 80 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 10 V/us
Number of Channels 1
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Pbfree Code no
Physical
Surface Mount NO
Package / Case PDIP
Alternative Model
