OPA129UBG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Rail/Tube op amp amplifier circuit 4.9mm 100fA 9V 1000kHz
PDF
/
Buying Options
Total Price: USD $60.93
Unit Price: USD $60.925147
≥1 USD $60.925147
≥10 USD $57.476552
≥100 USD $54.223166
≥500 USD $51.153932
≥1000 USD $48.258425
Inventory: 8388
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.58mm
Technical
Power NO
Max I/O Voltage 2mV
Nominal Gain Bandwidth Product 1MHz
Dual Supply Voltage 9V
Programmable Power NO
Min Dual Supply Voltage 5V
Micropower NO
Low-Bias YES
Max Dual Supply Voltage 18V
Frequency Compensation YES
Low-Offset NO
Voltage Gain 120dB
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 1MHz
Bandwidth 1MHz
Input Offset Voltage (Vos) 2mV
Output Current per Channel 10mA
Current - Input Bias 100 fA
Common Mode Rejection Ratio 80 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 2.5 V/μs
Current - Output 10mA
Nominal Supply Current 1.8mA
Operating Supply Current 1.2mA
Temperature Grade AUTOMOTIVE
Number of Elements 1
Operating Supply Voltage 18V
Pin Count 8
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e4
Packaging Rail/Tube
Physical
Number of Pins 8
Surface Mount YES
Package / Case SOIC
