LOG100JP
RoHS
RoHS compliant
RoHS compliantPackage 14-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified Through Hole Logarithmic and Log Ratio Logarithmic and Log Ratio Amplifier 600mW 0C~70C 45kHz 700muV
PDF
/
Buying Options
Total Price: USD $42.96
Unit Price: USD $42.9571
≥1 USD $42.9571
≥10 USD $35.2469
≥100 USD $34.1449
≥500 USD $33.04385
≥1000 USD $31.9428
Inventory: 659
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 20.065mm
Height Seated (Max) 5.46mm
Technical
-3db Bandwidth 45kHz
Neg Supply Voltage-Nom (Vsup) -15V
Supply Current-Max (Isup) 9mA
Bandwidth 0.045MHz
Input Offset Voltage (Vos) 700μV
Output Current per Channel 5mA
Voltage - Supply, Single/Dual (±) ±12V~18V
Current - Input Bias 1pA
Amplifier Type Logarithmic and Log Ratio
Quiescent Current 7mA
Power Dissipation 600mW
Operating Supply Current 7mA
Analog IC - Other Type LOG OR ANTILOG AMPLIFIER
Number of Circuits 1
Qualification Status Not Qualified
Pin Count 14
Base Part Number LOG100
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Max Power Dissipation 600mW
Subcategory Analog Computational Functions
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Package / Case 14-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
