LMV931IDCKR
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead GULL WING Rail-to-Rail Surface Mount General Purpose Amplifier 60dB 0.42V/mus -40C~125C 1.5MHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 3883
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Base Part Number LMV931
Pin Count 5
Output Type Rail-to-Rail
Number of Elements 1
Operating Supply Current 116μA
Nominal Supply Current 210μA
Output Current 100mA
Slew Rate 0.42V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 60 dB
Current - Input Bias 15nA
Voltage - Supply, Single/Dual (±) 1.8V~5V ±0.9V~2.5V
Output Current per Channel 100mA
Input Offset Voltage (Vos) 4mV
Bandwidth 1.5MHz
Unity Gain BW-Nom 1400 kHz
Voltage Gain 113dB
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 1mV
Low-Bias NO
Micropower YES
Programmable Power NO
Power NO
Dimensions
Length 2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
