LMV710IDBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead GULL WING Rail-to-Rail Surface Mount General Purpose Amplifier 50dB 5V/mus -40C~85C 5MHz
PDF
/
Buying Options
Total Price: USD $8.46
Unit Price: USD $8.45975
≥1 USD $8.45975
≥10 USD $6.9407
≥100 USD $6.7241
≥500 USD $6.5075
≥1000 USD $6.28995
Inventory: 2464
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Power NO
Programmable Power NO
Micropower NO
Low-Bias YES
Voltage - Input Offset 400μV
Supply Voltage Limit-Max 6V
Frequency Compensation YES
Low-Offset NO
Voltage Gain 123dB
Unity Gain BW-Nom 5000 kHz
Bandwidth 5MHz
Input Offset Voltage (Vos) 3mV
Output Current per Channel 40mA
Voltage - Supply, Single/Dual (±) 2.7V~5.5V
Current - Input Bias 4pA
Common Mode Rejection Ratio 50 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 5V/μs
Output Current 40mA
Nominal Supply Current 1.7mA
Operating Supply Current 1.17mA
Number of Channels 1
Output Type Rail-to-Rail
Pin Count 5
Base Part Number LMV710
Supply Voltage 2.7V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
