LMV321IDBVRQ1
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free Not Qualified GULL WING Rail-to-Rail General Purpose Amplifier 50dB 1V/mus -40C~85C 1MHz
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.09975
≥1 USD $0.09975
≥10 USD $0.0817
≥100 USD $0.0798
≥500 USD $0.07695
≥1000 USD $0.0741
Inventory: 184834
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LMV321
Pin Count 5
Qualification Status Not Qualified
Output Type Rail-to-Rail
Number of Elements 1
Operating Supply Current 130μA
Nominal Supply Current 250μA
Output Current 160mA
Slew Rate 1V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 50 dB
Current - Input Bias 15nA
Voltage - Supply, Single/Dual (±) 2.7V~5.5V ±1.35V~2.75V
Output Current per Channel 160mA
Input Offset Voltage (Vos) 7mV
Bandwidth 1MHz
Unity Gain BW-Nom 1000 kHz
Voltage Gain 100dB
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 1.7mV
Low-Bias NO
Micropower YES
Programmable Power NO
Power NO
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
