LMH6504MAX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant EAR99 LMH6504 Tin/Lead (Sn/Pb) op amp amplifier circuit 4.9mm 900nA 5V 65dB
PDF
/
Buying Options
Total Price: USD $4.74
Unit Price: USD $4.7367
≥1 USD $4.7367
≥10 USD $3.88645
≥100 USD $3.76485
≥500 USD $3.6442
≥1000 USD $3.5226
Inventory: 1120
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Supply Voltage 5V
Base Part Number LMH6504
Pin Count 8
Supply Voltage-Max (Vsup) 6V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 11mA
Nominal Supply Current 15mA
Slew Rate 1500V/μs
Amplifier Type General Purpose
Current - Input Bias 900nA
Voltage - Supply, Single/Dual (±) 7V~12V ±3.5V~6V
Output Current per Channel 80mA
Input Offset Voltage (Vos) 10mV
Gain Bandwidth Product 150MHz
Neg Supply Voltage-Nom (Vsup) -5V
Power Supply Rejection Ratio (PSRR) 65dB
Dual Supply Voltage 5V
Dimensions
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
