LM358APE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Rail/Tube op amp buffer circuit 9.81mm 0.1muA 9V 700kHz
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1615
≥1 USD $0.1615
≥10 USD $0.133
≥100 USD $0.12825
≥500 USD $0.12445
≥1000 USD $0.12065
≥5000 USD $0.10735
Inventory: 1140
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Through Hole
Package / Case PDIP
Number of Pins 8
Technical
Packaging Rail/Tube
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 2
Supply Voltage 5V
Pin Count 8
Operating Supply Voltage 16V
Number of Elements 2
Power Supplies +-1.5/+-15/3/30V
Temperature Grade COMMERCIAL
Max Supply Voltage 32V
Min Supply Voltage 3V
Operating Supply Current 1mA
Nominal Supply Current 1.2mA
Current - Output 30mA
Slew Rate 0.3 V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 65 dB
Current - Input Bias 100nA
Output Current per Channel 30mA
Input Offset Voltage (Vos) 3mV
Bandwidth 700 kHz
Gain Bandwidth Product 700 kHz
Unity Gain BW-Nom 700 kHz
Voltage Gain 100dB
Low-Offset NO
Frequency Compensation YES
Max Dual Supply Voltage 16V
Low-Bias NO
Micropower NO
Min Dual Supply Voltage 1.5V
Bias Current-Max (IIB) @25C 0.1μA
Programmable Power NO
Dual Supply Voltage 9V
Power NO
Input Offset Current-Max (IIO) 0.03μA
Dimensions
Height 5.08mm
Length 9.81mm
Width 6.35mm
Thickness 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
