LM258PE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Rail/Tube op amp buffer circuit 9.81mm 0.3muA 5mV 700kHz
PDF
/
Inventory: 9917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 9.81mm
Height 5.08mm
Technical
Input Offset Current-Max (IIO) 0.03μA
Power NO
Programmable Power NO
Bias Current-Max (IIB) @25C 0.15μA
Min Dual Supply Voltage 1.5V
Micropower NO
Low-Bias NO
Max Dual Supply Voltage 16V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.3μA
Voltage Gain 100dB
Unity Gain BW-Nom 700 kHz
Gain Bandwidth Product 700 kHz
Bandwidth 700 kHz
Input Offset Voltage (Vos) 5mV
Output Current per Channel 30mA
Current - Input Bias 150nA
Common Mode Rejection Ratio 70 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.3 V/μs
Current - Output 30mA
Nominal Supply Current 1.2mA
Operating Supply Current 1mA
Min Supply Voltage 3V
Max Supply Voltage 32V
Temperature Grade OTHER
Power Supplies +-1.5/+-15/3/30V
Number of Elements 2
Operating Supply Voltage 16V
Pin Count 8
Supply Voltage 5V
Number of Functions 2
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Rail/Tube
Physical
Number of Pins 8
Package / Case PDIP
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
