LM101AJ
RoHS
/
Package 8-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant EAR99 LM101 Tin/Lead (Sn/Pb) op amp buffer circuit 10.16mm 0.075muA 9.121518MV 1000000kHz
PDF
/
Buying Options
Total Price: USD $17.28
Unit Price: USD $17.2832
≥1 USD $17.2832
≥10 USD $15.9412
≥100 USD $15.22444
≥500 USD $13.61243
≥1000 USD $12.985535
≥3000 USD $12.35865
Inventory: 742
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 4.064mm
Width 6.502mm
Length 10.16mm
Height 5.08mm
Technical
Wideband NO
Dual Supply Voltage 9.121518MV
Programmable Power NO
Bias Current-Max (IIB) @25C 0.075μA
Micropower NO
Low-Bias NO
Voltage - Input Offset 700μV
Frequency Compensation NO
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 80dB
Average Bias Current-Max (IIB) 0.075μA
Voltage Gain 104.08dB
Unity Gain BW-Nom 1000000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Gain Bandwidth Product 1MHz
Input Offset Voltage (Vos) 2mV
Voltage - Supply, Single/Dual (±) 10V~44V ±5V~22V
Current - Input Bias 30nA
Common Mode Rejection Ratio 80 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 25mA
Power Dissipation 1W
Nominal Supply Current 1.2mA
Operating Supply Current 1.8mA
Power Supplies +-5/+-20V
Number of Elements 1
Operating Supply Voltage 22V
Pin Count 8
Base Part Number LM101
Terminal Pitch 2.54mm
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Number of Pins 8
Package / Case 8-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
