INA2128UG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 INA2128 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 10.3mm 0.005muA 15V 80dB
PDF
/
Buying Options
Total Price: USD $4.46
Unit Price: USD $4.460079
≥1 USD $4.460079
≥10 USD $1.726527
≥100 USD $1.665411
≥500 USD $1.636242
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Voltage Gain-Nom 10
Input Offset Current-Max (IIO) 0.005μA
Neg Supply Voltage-Max (Vsup) -18V
Dual Supply Voltage 15V
-3db Bandwidth 1.3MHz
Supply Voltage Limit-Max 18V
Average Bias Current-Max (IIB) 0.005μA
Voltage Gain 80dB
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 1.3MHz
Input Offset Voltage (Vos) 10μV
Output Current per Channel 15mA
Voltage - Supply, Single/Dual (±) 4.5V~36V ±2.25V~18V
Current - Input Bias 20nA
Common Mode Rejection Ratio 120 dB
Amplifier Type Instrumentation
Slew Rate 4V/μs
Quiescent Current 700μA
Max Supply Current 1.5mA
Nominal Supply Current 1.5mA
Operating Supply Current 1.4mA
Number of Circuits 2
Number of Elements 6
Pin Count 16
Base Part Number INA2128
Supply Voltage 15V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Resistance 100GOhm
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 420.395078mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
