UA741MN
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 UA741 Matte Tin (Sn) op amp buffer circuit 2.54mm 0.2muA 5mV 1000kHz
PDF
/
Inventory: 5464
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature -55°C~125°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 2.54mm
Base Part Number UA741
Pin Count 8
Operating Supply Voltage 20V
Number of Elements 1
Operating Supply Current 1.7mA
Nominal Supply Current 2.8mA
Power Dissipation 500mW
Output Current 25mA
Slew Rate 0.5V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 70 dB
Current - Input Bias 10nA
Voltage - Supply, Single/Dual (±) 10V~44V ±5V~22V
Output Current per Channel 25mA
Input Offset Voltage (Vos) 5mV
Gain Bandwidth Product 1MHz
Neg Supply Voltage-Nom (Vsup) -15V
Unity Gain BW-Nom 1000 kHz
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.2μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 22V
Voltage - Input Offset 1mV
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
