UA741CDT
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 UA741 Tape & Reel (TR) op amp amplifier circuit 5mm 0.2muA 5mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.53856
≥100 USD $0.505472
≥500 USD $0.412632
≥1000 USD $0.383258
≥3000 USD $0.326198
Inventory: 14462
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.25mm
Technical
Voltage - Input Offset 1mV
Supply Voltage Limit-Max 22V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.2μA
Voltage Gain 106.02dB
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 1MHz
Input Offset Voltage (Vos) 5mV
Output Current per Channel 25mA
Voltage - Supply, Single/Dual (±) 10V~44V ±5V~22V
Current - Input Bias 10nA
Common Mode Rejection Ratio 70 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 25mA
Power Dissipation 500mW
Nominal Supply Current 2.8mA
Operating Supply Current 1.7mA
Number of Channels 1
Operating Supply Voltage 20V
Pin Count 8
Base Part Number UA741
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 500mW
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 4.535924g
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 10 Weeks
