TSV852IYST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TSV852 Cut Tape (CT) op amp buffer circuit 3mm 0.36mA 4mV 1300kHz
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.8568
≥1 USD $1.8568
≥10 USD $1.66584
≥100 USD $1.57168
≥500 USD $1.339184
≥1000 USD $1.257485
≥3000 USD $1.100282
Inventory: 4030
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 3mm
Height Seated (Max) 1.1mm
Technical
Input Offset Current-Max (IIO) 0.05μA
Power NO
Wideband NO
Programmable Power NO
Bias Current-Max (IIB) @25C 0.06μA
Micropower YES
Low-Bias NO
Supply Voltage Limit-Max 6V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.11μA
Voltage Gain 110dB
Unity Gain BW-Nom 1300 kHz
Gain Bandwidth Product 1.3MHz
Input Offset Voltage (Vos) 4mV
Output Current per Channel 70mA
Voltage - Supply, Single/Dual (±) 2.5V~5.5V
Current - Input Bias 27nA
Common Mode Rejection Ratio 72 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.7V/μs
Supply Current-Max 0.36mA
Operating Supply Current 130μA
Number of Circuits 2
Output Type Rail-to-Rail
Base Part Number TSV852
Terminal Pitch 0.65mm
Supply Voltage 2.7V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 20 Weeks
