TSV6392IDT
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TSV6392 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 5mm 0.0001muA 3mV 2000kHz
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 1970
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.25mm
Technical
Bias Current-Max (IIB) @25C 0.00001μA
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 6V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0001μA
Voltage Gain 98dB
Unity Gain BW-Nom 2000 kHz
Bandwidth 2.4MHz
Input Offset Voltage (Vos) 3mV
Output Current per Channel 72mA
Voltage - Supply, Single/Dual (±) 1.5V~5.5V
Current - Input Bias 1pA
Common Mode Rejection Ratio 60 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 1.1V/μs
Output Current 72mA
Nominal Supply Current 60μA
Operating Supply Current 60μA
Number of Channels 2
Output Type Rail-to-Rail
Pin Count 8
Base Part Number TSV6392
Supply Voltage 1.8V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 20 Weeks
