TSV6294AIPT
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free GULL WING Rail-to-Rail Surface Mount General Purpose Amplifier 60dB 0.5V/mus -40C~125C 1.3MHz
PDF
/
Buying Options
Total Price: USD $1.79
Unit Price: USD $1.7864
≥1 USD $1.7864
≥10 USD $1.606
≥100 USD $1.51536
≥500 USD $1.291136
≥1000 USD $1.212323
≥3000 USD $1.060787
Inventory: 1133
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 5mm
Technical
Bias Current-Max (IIB) @25C 0.00001μA
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 6V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0001μA
Voltage Gain 98dB
Unity Gain BW-Nom 1100 kHz
Bandwidth 1.3MHz
Input Offset Voltage (Vos) 800μV
Output Current per Channel 74mA
Voltage - Supply, Single/Dual (±) 1.5V~5.5V
Current - Input Bias 1pA
Common Mode Rejection Ratio 60 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 74mA
Nominal Supply Current 36μA
Operating Supply Current 29μA
Number of Circuits 4
Number of Channels 2
Power Supplies 1.8/5V
Output Type Rail-to-Rail
Pin Count 14
Base Part Number TSV6294
Terminal Pitch 0.65mm
Supply Voltage 1.8V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
