TSM104AIDT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TSM104 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 9.9mm 0.2muA 3mV 900kHz
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9944
≥1 USD $0.9944
≥10 USD $0.89144
≥100 USD $0.846208
≥500 USD $0.695024
≥1000 USD $0.649722
≥3000 USD $0.574165
Inventory: 1023
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number TSM104
Pin Count 16
Operating Supply Voltage 15V
Number of Elements 4
Operating Supply Current 1.4mA
Nominal Supply Current 2.4mA
Slew Rate 0.3V/μs
Amplifier Type General Purpose
Common Mode Rejection Ratio 70 dB
Current - Input Bias 20nA
Voltage - Supply, Single/Dual (±) 3V~32V ±1.5V~16V
Output Current per Channel 40mA
Input Offset Voltage (Vos) 3mV
Gain Bandwidth Product 900kHz
Unity Gain BW-Nom 900 kHz
Voltage Gain 100dB
Average Bias Current-Max (IIB) 0.2μA
Supply Voltage Limit-Max 36V
Voltage - Input Offset 500μV
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
