TSH330ID
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TSH330 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 5mm 20.2mA 3.1mV 56dB
PDF
/
Inventory: 8290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.25mm
Technical
Programmable Power NO
Bias Current-Max (IIB) @25C 55μA
-3db Bandwidth 1.5GHz
Micropower NO
Low-Bias NO
Voltage - Input Offset 180μV
Supply Voltage Limit-Max 3V
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 56dB
Neg Supply Voltage-Nom (Vsup) -2.5V
Bandwidth 1.1 GHz
Input Offset Voltage (Vos) 3.1mV
Output Current per Channel 453mA
Voltage - Supply, Single/Dual (±) 4.5V~5.5V ±2.25V~2.75V
Current - Input Bias 26μA
Common Mode Rejection Ratio 50 dB
Amplifier Type Current Feedback
Slew Rate 1800V/μs
Supply Current-Max 20.2mA
Power Dissipation 830mW
Operating Supply Current 16.6mA
Number of Channels 1
Operating Supply Voltage 5V
Output Voltage 1.64V
Pin Count 8
Base Part Number TSH330
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 830mW
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
