TSH300ILT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TSH300 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 2.9mm 46muA 1.8mV 76dB
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.1198
≥1 USD $3.1198
≥10 USD $2.5593
≥100 USD $2.4795
≥500 USD $2.3997
≥1000 USD $2.3199
Inventory: 1433
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Wideband YES
Programmable Power NO
Bias Current-Max (IIB) @25C 46μA
-3db Bandwidth 200MHz
Micropower NO
Low-Bias NO
Voltage - Input Offset 500μV
Supply Voltage Limit-Max 3V
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 76dB
Voltage Gain 67dB
Neg Supply Voltage-Nom (Vsup) -2.5V
Input Offset Voltage (Vos) 1.8mV
Output Current per Channel 82mA
Voltage - Supply, Single/Dual (±) 4.5V~5.5V ±2.25V~2.75V
Current - Input Bias 30μA
Common Mode Rejection Ratio 60 dB
Amplifier Type Voltage Feedback
Slew Rate 230V/μs
Power Dissipation 500mW
Nominal Supply Current 19.5mA
Operating Supply Current 15.3mA
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 5
Base Part Number TSH300
Supply Voltage 2.5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 500mW
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
