TSB712IST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant S-PDSO-G8 TSB712 Tape & Reel (TR) op amp buffer circuit 3mm 0.9muA 1400muV 6000kHz
PDF
/
Buying Options
Total Price: USD $2.3
Unit Price: USD $2.300614
≥1 USD $2.300614
≥10 USD $2.170394
≥100 USD $2.047537
≥500 USD $1.931642
≥1000 USD $1.822299
Inventory: 1434
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Subcategory Operational Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TSB712
JESD-30 Code S-PDSO-G8
Output Type Rail-to-Rail
Number of Circuits 2
Current - Supply 1.8mA
Slew Rate 3V/μs
Amplifier Type General Purpose
Common Mode Rejection Ratio 105 dB
Voltage - Supply, Single/Dual (±) 2.7V~36V ±1.35V~18V
Gain Bandwidth Product 6MHz
Unity Gain BW-Nom 6000 kHz
Average Bias Current-Max (IIB) 0.9μA
Supply Voltage Limit-Max 40V
Current - Output / Channel 50mA
Input Offset Voltage-Max 1400μV
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Compliance
RoHS Status ROHS3 Compliant
