TS514AIDT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS514 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 8.65mm 0.3muA 500muV 3000kHz
PDF
/
Buying Options
Total Price: USD $2.56
Unit Price: USD $2.5608
≥1 USD $2.5608
≥10 USD $2.3012
≥100 USD $2.171136
≥500 USD $1.84976
≥1000 USD $1.736909
≥3000 USD $1.519778
Inventory: 3871
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Neg Supply Voltage-Max (Vsup) -18V
Bias Current-Max (IIB) @25C 0.15μA
Micropower YES
Supply Voltage Limit-Max 18V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.3μA
Voltage Gain 100dB
Unity Gain BW-Nom 3000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 3MHz
Input Offset Voltage (Vos) 500μV
Output Current per Channel 23mA
Voltage - Supply, Single/Dual (±) 6V~30V ±3V~15V
Current - Input Bias 50nA
Common Mode Rejection Ratio 90 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 1.5V/μs
Output Current 23mA
Power Dissipation 400mW
Nominal Supply Current 2.4mA
Operating Supply Current 1.4mA
Power Supplies +-15V
Number of Elements 4
Pin Count 14
Base Part Number TS514
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 400mW
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 10 Weeks
