TS27M4CPT
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS27M4 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 5mm 0.00015muA 10mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 984
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 5mm
Height Seated (Max) 1.2mm
Technical
Micropower YES
Low-Bias YES
Voltage - Input Offset 1.1mV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.00015μA
Voltage Gain 93.98dB
Unity Gain BW-Nom 1000 kHz
Gain Bandwidth Product 1MHz
Input Offset Voltage (Vos) 10mV
Output Current per Channel 45mA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Current - Input Bias 1pA
Common Mode Rejection Ratio 65 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.6V/μs
Output Current 45mA
Nominal Supply Current 800μA
Operating Supply Current 150μA
Power Supplies 10V
Number of Elements 4
Operating Supply Voltage 8V
Pin Count 14
Base Part Number TS27M4
Terminal Pitch 0.65mm
Supply Voltage 10V
Number of Functions 4
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
