TS27L2BCDT
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS27L2 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 4.9mm 0.00015muA 2mV 100kHz
PDF
/
Inventory: 5141
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 10V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number TS27L2
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 8V
Number of Elements 2
Power Supplies 5/10V
Operating Supply Current 10μA
Nominal Supply Current 30μA
Output Current 60mA
Slew Rate 0.04V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 65 dB
Current - Input Bias 1pA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Output Current per Channel 45mA
Input Offset Voltage (Vos) 2mV
Gain Bandwidth Product 100kHz
Unity Gain BW-Nom 100 kHz
Voltage Gain 100dB
Average Bias Current-Max (IIB) 0.00015μA
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 250μV
Low-Bias YES
Micropower YES
Programmable Power NO
Wideband NO
Power NO
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
