TS274ID
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS274 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 8.65mm 0.0003muA 10mV 3500kHz
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.53485
≥1 USD $0.53485
≥10 USD $0.4389
≥100 USD $0.4256
≥500 USD $0.41135
≥1000 USD $0.39805
Inventory: 1259
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Low-Bias YES
Voltage - Input Offset 1.1mV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0003μA
Voltage Gain 83.52dB
Unity Gain BW-Nom 3500 kHz
Gain Bandwidth Product 3.5MHz
Input Offset Voltage (Vos) 10mV
Output Current per Channel 45mA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Current - Input Bias 1pA
Common Mode Rejection Ratio 65 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 5.5V/μs
Output Current 60mA
Nominal Supply Current 6mA
Operating Supply Current 1mA
Power Supplies 3/16V
Number of Elements 4
Operating Supply Voltage 8V
Pin Count 14
Base Part Number TS274
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 10V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
