TS272BIDT
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS272 Matte Tin (Sn) - annealed op amp amplifier circuit 5mm 0.0003muA 2mV 3500kHz
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.98
≥1 USD $1.98
≥10 USD $1.78112
≥100 USD $1.680096
≥500 USD $1.431408
≥1000 USD $1.344042
≥3000 USD $1.176032
Inventory: 1134
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.65mm
Technical
Power NO
Programmable Power NO
Max Frequency 100kHz
Micropower NO
Low-Bias YES
Voltage - Input Offset 250μV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0003μA
Voltage Gain 83.52dB
Unity Gain BW-Nom 3500 kHz
Bandwidth 3.5MHz
Input Offset Voltage (Vos) 2mV
Output Current per Channel 45mA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Current - Input Bias 1pA
Common Mode Rejection Ratio 65 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 5.5V/μs
Output Current 60mA
Nominal Supply Current 3mA
Operating Supply Current 1mA
Power Supplies 10V
Number of Elements 2
Operating Supply Voltage 8V
Pin Count 8
Base Part Number TS272
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 10V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 10 Weeks
