TS1874IN
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TS1874 Matte Tin (Sn) op amp buffer circuit 5.1mm 0.15muA 100muV 1600kHz
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 1173
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifier
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 1.8V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TS1874
Pin Count 14
Qualification Status Not Qualified
Output Type Rail-to-Rail
Operating Supply Voltage 6V
Power Supplies 2/5.5V
Number of Circuits 4
Operating Supply Current 500μA
Nominal Supply Current 560μA
Output Current 68mA
Slew Rate 0.6V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 55 dB
Current - Input Bias 70nA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Output Current per Channel 80mA
Input Offset Voltage (Vos) 100μV
Gain Bandwidth Product 1.8MHz
Unity Gain BW-Nom 1600 kHz
Voltage Gain 92dB
Average Bias Current-Max (IIB) 0.15μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 7V
Low-Bias NO
Micropower YES
Bias Current-Max (IIB) @25C 0.13μA
Programmable Power NO
Wideband NO
Power NO
Dimensions
Height Seated (Max) 5.1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
