TS1874AIYDT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
GULL WING Rail-to-Rail Surface Mount General Purpose General Purpose Amplifier 55dB 0.6V/mus -40C~125C 1.8MHz
PDF
/
Buying Options
Total Price: USD $2.97
Unit Price: USD $2.9656
≥1 USD $2.9656
≥10 USD $2.66024
≥100 USD $2.515392
≥500 USD $2.179936
≥1000 USD $2.068176
≥3000 USD $1.855762
Inventory: 1139
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Input Offset Current-Max (IIO) 0.06μA
Power NO
Wideband NO
Programmable Power NO
Bias Current-Max (IIB) @25C 0.125μA
Micropower YES
Low-Bias NO
Supply Voltage Limit-Max 7V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.15μA
Voltage Gain 97dB
Unity Gain BW-Nom 1600 kHz
Gain Bandwidth Product 1.8MHz
Input Offset Voltage (Vos) 100μV
Output Current per Channel 80mA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Current - Input Bias 70nA
Common Mode Rejection Ratio 55 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.6V/μs
Output Current 68mA
Nominal Supply Current 560μA
Operating Supply Current 500μA
Number of Circuits 4
Power Supplies 2/5V
Output Type Rail-to-Rail
Pin Count 14
Base Part Number TS1874
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 1.8V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 10 Weeks
